CHT-B401
The dedicated AI video terminal for forklifts adopts Huawei HiSilicon's highest in car technology, and is the world's first in car video recorder built with an integrated AI DVR chip. It is a truly intelligent single chip active safety in car video terminal. The chip supports a neural network inference engine, with super strong computational performance! Compared to traditional non AI chips and weakly computing AI chips for active safety in vehicle terminals, the algorithm accuracy can be improved by 30%, greatly reducing false positives and false positives. Integrate deep learning algorithms to completely solve the problem of false positives. Low power consumption, ultra-high stability!
Key words:
Classification:
CHT-B401
Contact Us
Product Description
Product Features:
 |
 |
 |
|
Multiplexing 8 channels of AHD analog video input 1 digital video input 3 channels of video output |
Data features Hard disk plus SD card storage Resist the vibration of dust on the car Resulting in data corruption |
Exclusive pre-allocation Vehicle-specific file system technology Safeguard data integrity |
 |
 |
 |
|
Power-off protection Special UPS technology Completely cut off external/backup power |
A variety of video recordings Automatic/manual recording Alarm recording |
Communication module Support GPS/BD Beidou III generation 4G module |
Specifications
|
Product type |
AI Video Terminal for Forklift (CHT-B401) |
|
operating system |
Embedded Linux |
|
Processor speed |
1.2GHZ |
|
NOR FLASH capacity |
32MB NOR+128M NAND |
|
RAM capacity |
1G |
|
Drive record |
15 days or 100,000 ≥ |
|
Alarm input |
8 channels of IO alarm input, 2 channels of AD input, 2 channels of pulse speed input; It has the function of alarm linkage |
|
Alarm output |
2-way switching output, linkage sound and light alarm, oil and power cut-off, etc |
|
Security management |
User password and administrator password are managed at two levels |
|
Video and codecs |
8 AHD HD analog inputs, head interface, 1.0Vp-p, 75Ω 1 IPC digital signal input |
|
2 composite video outputs, 1 VGA output. 1.0Vp-p, 75Ω, Support 单 screen / 2 screen / 4 screen / 5 screen / 6 screen split |
|
|
支持单 screen/2 screen/4 screen/5 screen/6 screen/8 screen/9 screen拼接预览, Support manual/event trigger full-screen display function |
|
|
Support 1080P, 960P, 720P, D1, HD1, CIF optional, It can support up to 2 channels of 1080P input |
|
|
Recordings from 0 to 7 are available, with 0 levels at the top and 7 levels at the minimum |
|
|
H.265/H.264 |
|
|
Default automatic recording, support ignition recording, manual recording, alarm recording, etc |
|
|
4-core 12M-4B headphone head/4-core 3.5mm headphone jack |
|
|
Audio output |
|
|
Number of output channels: 3 channels |
|
|
Support mute function |
|
|
Location features |
Support dual-mode positioning (Beidou 3rd generation) |
|
Accuracy≤10m (95% probability) |
|
|
Hot start ≤ 5s, cold start ≤ 45s |
|
|
Repeat positioning: 1S |
Product parameters
| project | Technical parameters |
| Operating voltage | DC 12V ~DC 32V |
| Operating current | <20 mA |
| Operating frequency | 433.92 MHz ± 30KHZ |
| RF transmit signal modulation | FSK |
| RF transmit signal transmit power | FSK |
| RF transmit signal reception sensitivity | ＜-105dbm |
| Operating temperature | -40℃~85℃ |
Applicable scenarios
 |
 |
 |
 |
| Muck truck operation | Smart shipping | Operation of large cargo transport vehicles | Campus operations |
